Degelman Blades

Degelman Industries has been engineering tough, high performance equipment for almost 60 years. The result is outstanding equipment that exceeds expectations and outperforms. We achieve this through meticulous design and vigilant customer service.

No two tractor manufacturers are alike, so we don’t develop a blade that is “one size fits all. Degelman engineers, designs and individually builds all Bulldozer Tractor fit-ups to ensure proper mounting locations are the best spot to push from – protecting your tractor investment. Featuring a Precision Machined Tubing Finish, Superior Seals and High Grade Wear Bands the Degelman series of Bulldozer Blades adds value and versatility to your tractor.

3500 Series Blades

Designed for 40-150 horsepower 2WD tractors, skid steers, front-end-loaders and most front-wheel-assisted tractors, the 3500 series gives you the robust blade design Degelman is known for in a compact blade.

Benefit from 0° to 18° two-way hydraulic angling that allows you to choose any angle you want; our tool-less D-lock® Quick-Tach mounting system so one person can attach/detach the blade in minutes; double-skin construction and AR400 reversible skid shoes.

Features

• Available in 8ft, 9ft, 10ft & 12ft widths. (Note: Larger blade widths may not be compatible will all tractors)
• Compatible with 2WD tractors, skid steer loaders, front-end loaders and front-wheel-assisted tractors.
• 18° two-way hydraulic angling on 2WD and front-wheel-assisted tractors.
• 30° two-way hydraulic angling on skid steers and front-end- loaders.
• Attaches in minutes with D-lock® Quick-Tach.
• One-person tool-less attaching/detaching.
• Unique-mounting design.
• No welding: minimal bolt-on brackets only.
• Integrated front weight bracket.
• Double-skin blade construction.
• Industrial-strength cylinders.
• Reversible, adjustable AR400 skid shoes.
• Ripple-formed blade.

Range Of Motion

A. Skid Steer

B. Loader

C. Tractor Mount / 3PT

Rear Axle / Front Hook Mount

3500 Blades commonly mount using a front mounted hook and two rear axle brackets. The operator typically drives into the front hook, connects the hydraulics, hydraulically lifts the rear frame into position, and secures the “D-Lock” connections on the rear axle brackets. (46/5700 shown in illustration)

No Welding – Easy Bolt-On Assembly

Simple, Bolt-on brackets are all that is attached to your tractor. The rest of the assembly quickly attaches and detaches from these simple brackets. The brackets can also be removed if needed!

Quick-Attach D-Lock® Mounting

The D-Lock® mounting system offers the convenience of quick attach/detach as well as long life. No tools are required. Fit-ups are 100% secure with zero movement. The blade can be removed in minutes by disengaging two points on the front axle brackets.
