BBFB10-ATV

B&B 10′ Coverage Folding Spray Boom With ATV Sprayer Mounts | 3 Flood Nozzles On 40″ Spacing

$250.00

 B&B 10′ Coverage Folding Spray Boom With ATV Sprayer Mounts | 3 Flood Nozzles On 40″ Spacing

 PRICE DOES NOT INCLUDE SETUP OR SHIPPING – PRICED FOB FACTORY



B&B 10′ Spray Coverage Booms | 3 Nozzles

Fasten Boom Mounts to the ATV’s rear rack using U-Bolts and 5/16” LockNuts. The Boom Mounts can be mounted in two positions for spraying in areas with short or tall weeds. For spraying areas with tall weeds, simply reverse the Boom Mounts so they come straight out from the ATV rack and point upward.

Boom Plumbing

  1. Install 3/8xCL Nipple #21 into Spot Sprayer Pump
  2. Screw the black 3/8”Tee into the Nipple
  3. Install 3/8” Ball Valve into one side of Black Tee
  4. Screw 3/8” Hose Barb into 3/8”Ball Valve
  5. Connect 3/8“ Hose to Hose Barb and 3/8“ Nozzle Tee
  6. Connect Handgun and Hose assembly to the remaining open end of the black 3/8” Tee
  7. Tighten all Hose Clamps & Boom Bolts

Boom Hinge
