H&S HPH4242 Hydra-Push Manure Spreader | 246.53 Cu Ft Struck | Horiz. Beaters

PRICE DOES NOT INCLUDE SETUP OR SHIPPING – PRICED FOB FACTORY

BACK FREIGHT – $1,450

Must Add PTO / Hitch / Tires & Rims To Complete

Tractor Requirement – Once The Spreader Is Loaded, It Shouldn’t Weight More Than 1.5 Times The Weight Of The Tractor

Note: Average Manure Weight Is: 55-70 lbs. per Cu. Ft

Unit	HPH4242	HPH4255	HPV4242	HPV4255
Capacity – Old Rating	425 bu	550 bu	425 bu	550 bu
Capacity – Cu. Ft Struck Level Per ASAE S324.2	246.53	383.39	246.53	383.39
Capacity Cu. Ft. Heaped Per ASAE S324.2	374.41	511.27	374.41	511.27
Side Loading Height	61 ¼″ (61.3 cm)	81″ (205.7 cm)	61 ¼″ (61.3 cm)	81″ (205.7 cm)
2nd Beater Height	74 ¾” (190 cm)	86 ¾″ (220 cm)	–	–
Vertical Beater Height	–	–	104 ½″ (265 cm)	121 ½″ (308 cm)
Height – Top of Hyd. Endgate	65″ (165 cm)	85 ½″ (218 cm)	65″ (165 cm)	85 ½″ (218 cm)
Height at Top of Pusher	76″ (193 cm)	95″ (241 cm)	–	–
Height – Top of Screen	–	–	98″ (249 cm)	117″ (297 cm)
Inside Width	72″ (183 cm)	72″ (183 cm)	72″ (183 cm)	72″ (183 cm)
Inside Length	15′ (4.6 m)	15′ (4.6 m)	15′ (4.6 m)	15′ (4.6 m)
Inside Depth	34″ (86 cm)	53″ (135 cm)	34″ (86 cm)	53″ (135 cm)
Overall Width w/Tires	10′ 2″ (310 cm)	10′ 2″ (310 cm)	10′ 2″ (310 cm)	10′ 2″ (310 cm)
Overall Length	28′ (8.5 m)	28′ (8.5 m)	29′ 1″ (8.9 m)	29′ 1″ (8.9 m)
Standard Number of Beaters	2	2	2	2
Horizontal Beater Diameter/Lower	29″ (71 cm)	29″ (71 cm)	–	–
Horizontal Beater Diameter/Upper	20″ (51 cm)	29″ (71 cm)	–	–
Vertical Beater Diameter	–	–	34″ (86 cm)	34″ (86 cm)
Replaceable Beater Paddles	Yes	Yes	Yes	Yes
Removeable Beater Assembly	Yes	Yes	Yes	Yes
Hub	8 Bolt	10 Bolt	8 Bolt	10 Bolt
Hitch Choices	Clevis or Bullnose	Clevis or Bullnose	Clevis or Bullnose	Clevis or Bullnose
Tire Choices	425 x 22.5, 19L x 16.1 10 Ply, or 550/45 x 22.5	425 x 22.5 Used Truck Tires, or Heavy-Duty Tandem Axle w/600/50 x 22.5	425 x 22.5, 19L x 16.1 10 Ply, or 550/45 x 22.5	425 x 22.5 Used Truck Tires, or Heavy-Duty Tandem Axle w/600/50 x 22.5
Hydraulic Endgate	Standard	Standard	Standard	Standard
Poly Side Rails	Standard	Standard	Standard	Standard
PTO Choices	1 ⅜” or 1 ¾” 1000 RPM PTO w/Overrunning Clutch	1 ⅜” or 1 ¾” 1000 RPM PTO w/Overrunning Clutch	1 ⅜” or 1 ¾” 1000 RPM PTO w/Overrunning Clutch	1 ⅜” or 1 ¾” 1000 RPM PTO w/Overrunning Clutch
Hydraulic Push Cylinder Diameter	3 ½″	4 ½″	3 ½″	4 ½″
Weight w/Tires	7,000 lbs.	8,500 lbs.	8,800 lbs.	11,000 lbs.
Rear Hydraulic Endgate	Standard	Standard	Standard	Standard

MSHPH4242

MSHPH4242 Spreaders

Horizontal beaters.
All Hydraulic Push models use solid virgin grade poly with UV inhibitor, for the floor and sides allowing less friction.
The hydraulic endgate has 2 cylinders with ⅜″ hose and pipe for faster operation in cold weather.
A top beater is standard equipment.
Heavy duty rectangular tubing is used for the pole to ensure strength and long life. Structural channel floor supports spaced 9 ½″ apart are used for maximum floor support.
The HP’s PTO beater drive system is driven by the unique center drive system that consists of a straight shaft off the PTO underneath the manure spreader to an angle gearbox in the rear, and over to the beater drive sprocket.
#80 chains are used for strength and long life and easy open shields makes lubrication easy.
The Hydraulic Push-Off System on all models features two hydraulic cylinders that sequence to reduce push-off forces for fast unloading of material.
Beater blades are replaceable and the beater assembly is removable for stockpiling manure.
Removal of the beater assembly is done by simply removing the mounting bolts and a drive chain.
Choice of bullnose or clevis hitch
Poly bump rails
Constant velocity PTO
LED highway lighting
Easy open shields makes lubing of bearings easy.
