Name: WL1P14
SKU: 81155
Availability: InStock

Baumalight 1P14 Stump Grinder | 20-45 HP | CAT 1 QH-Compatible | 540 RPM | 2″ Max Cut Depth Per Pass

PRICE DOES NOT INCLUDE SETUP OR SHIPPING – PRICED FOB BV-ATWOOD, KS

Tractor Must Have Hydrostatic Drive

Does Your Tractor Require An Extension Kit? See Tab Below To Find Out

1P14 – 3 Point Hitch Stump Grinder For Subcompact Tractors

The 1P14 PTO stump grinder is a new model designed for small tractors equipped with hydrostatic drive and Category I 3PH and being released with a pre-production discount in February 2025. This tractor mounted stump grinder model allows you to grind small stumps efficiently with a 16″ Rotor, carrying 12 replaceable round teeth, and has a cutting height of 10″ above ground and 5″ below ground with a cutting wheel speed of 540 RPM. The high-speed carbide tipped teeth feature round tooth construction for superior cutting performance and can be rotated 3 times. The maximum cutting depth per pass is 2″ and the maximum horizontal cut is 18″. With no hydraulics required, this versatile PTO Stump Grinder is controlled with gravity feed which is ideal for tractors with no hydraulic remotes. In case of a sudden advance of the tractor, while grinding, the hinge will automatically swing the grinding head out a bit, keeping even pressure on the stump. This safety feature helps prevent damage to both the equipment and the operator. The stump grinder unit weight is 360 Lbs having a width of 36″ and length of 30″, making it compact and easy to maneuver in tight spaces.

All Baumalight stump grinders are made in Canada and offered through most farm and equipment dealers so you always will have local support to service or support for your stump grinder which is always best. If you don’t mind servicing your own equipment then buying from some of our internet dealers who drop ship to end users might also be a good option for you, if you cannot get a response from your local dealer.

We offer a free 6-pack of teeth with the purchase of a new unit, ensuring you have spare parts on hand and will direct ship any replacement parts to end users if our dealer so requests, we even support warranty work done by end users if that is more ideal for both the dealer and end user. All sales must be through dealers and we will cover a reasonable amount of time if the dealer does warranty work when the end user takes the unit to the dealer for repairs, but many times an end user will spend less time replacing a part at home, then traveling to a dealer so we will support what makes the most sense.

Model No.	1P14	1P24	3P24	3P34	3P40
Recommended HP Size	20-45	20-45	25-55	45-80	60-120
Maximum Engine HP	45	50	58	85	125
Maximum PTO HP	35	40	50	75	115
Transmission	Hydrostatic only	Hydrostatic only	Any	Any	Any
Hydraulic GPM	—	—	5–20	5–20	5–20
Rotor Size	16″	24″	24″	34″	34″
Number of Teeth	12	34	34	52	52
Tooth Part number	H3000	S1000	S1000	S1000	S1000
Tooth Construction	High speed round tooth	Carbide steel bolt-in	Carbide steel bolt-in	Carbide steel bolt-in	Carbide steel bolt-in
Cutting Wheel Speed	540 RPM	540 RPM	810 RPM	810 RPM	1000 RPM
Cutting Height – Above Ground	10″	10″	18″	25″	25″
Cutting Depth – Below Ground	5″	6″	8″	14″	14″
Maximum Cutting Depth – Per Pass	2″	5″	6″	9″	9″
Maximum Horizontal Cut	18″	22″	22″	32″	32″
Swing Arc	0°	0°	65°	65°	65°
Hub Torque	664 Ft.-Lbs.	885 Ft.-Lbs.	885 Ft.-Lbs.	1475 Ft.-Lbs.	1327 Ft.-Lbs.
Over Torque Protection	Slip clutch	Slip clutch	Slip clutch	Slip clutch	Slip clutch
Hitch	Cat I	Cat I	Cat I or II	Cat II	Cat II
Quick hitch compatibility	Yes	Yes	No	No	No
No. of Remotes Required – Hydraulic	0	0	1 or 2	1 or 2	1 or 2
Requires 12 Volt DC	No	No	No	No	No
Input Speed	540	540	540	540	1000
Unit Weight (Shipping) Lbs.	360	450	920	1231	1280
Width (Shipping)	36″	36″	42″	48″	48″
Length (Shipping)	30″	30″	49″	54″	54″

QUICK HITCH COMPATIBLE

Quick Hitch Compatible

The 1P14 Stump Grinder is CAT 1 Quick Hitch compatible, allowing you to easily connect to your compact tractor.

SLIP CLUTCH PTO SHAFT

Slip Clutch PTO Shaft

The 1P14 Stump Grinder includes a slip clutch PTO shaft. In the event that the grinder hits a rock, the slip clutch is designed to slip so that the shaft is not damaged. (this started in mid 2020).

SELF-REGULATING FEED

Self-Regulating Feed

For smoother operation, the 1P14 3-point hitch stump grinder features a self-regulating feed function that uses the weight of the grinder head. If you suddenly advance your tractor while grinding, a hinge will automatically swing the grinding head out a bit, keeping even pressure on the stump.

HIGH SPEED TEETH

The concave shaped carbide tip of our High Speed Teeth provide aggressive cutting action by chipping the brush bit by bit. This round tooth is 3 teeth in 1. Simply loosen the lock nut and rotate the tooth to a fresh, sharp cutting edge. This can be done three times, extending the life of each tooth.

MORE TEETH

More Teeth

The high number of teeth means that each tooth needs to do less work. Each of the Stump Blasters teeth only need to make a small cut, because the work is shared by more of our rugged teeth they last longer and usually only require 2 or 3 replacements at a time. The bolt-on designed teeth allow for straightforward replacement.

6 FREE TEETH

All 1P14 Stump Grinder comes with a free set of 6 replacement teeth. These replacement teeth are conveniently shipped in the owner’s manual tub bolted to the frame.

ROTOR

Rotor

The massive ½” thick steel rotor provides the back bone for the Stump Blaster cutting system. It’s the anchor for the carbide tipped teeth. For smooth operation it’s important that the rotor remains solid, with no flexing. The rugged rotor also provides the Stump Blaster with the extra momentum needed when the grinding is tough, making sure the Stump Blaster can power through the hardest stumps.

MORE CLEARANCE

More Clearance

The Stump Blaster’s carbide teeth extend a full 1-¼ inches from the rotor. This prevents chips and mulch from getting plugged. More chip clearing produces smoother operation and reduces heat build-up that can damage the rotor and cause premature tooth failure.

GREASEABLE PINS

Greaseable Pins

Our grease pins are zinc plated to prevent corrosion which will allow for smoother operation of the units joints over their lifetime.

1P14

12″ x 12″ cut

Price	18Hp	20Hp	30Hp	40Hp	60Hp	70Hp	80Hp	90Hp	120Hp
—	18 min	12 min	10 min	8 min	—	—	—	—	—

1P24

12″ x 12″ cut

Price	18Hp	20Hp	30Hp	40Hp	60Hp	70Hp	80Hp	90Hp	120Hp
—	—	12 min	10 min	8 min	—	—	—	—	—

1P24

Price	20Hp	30Hp	40Hp	60Hp	70Hp	80Hp	90Hp	120Hp
—	30 min	20 min	15 min	—	—	—	—	—

1P24 only must be mounted on a hydrostatic drive tractor

3P24

Price	20Hp	30Hp	40Hp	60Hp	70Hp	80Hp	90Hp	120Hp
—	—	15 min	12 min	10 min	—	—	—	—

3P34

Price	20Hp	30Hp	40Hp	60Hp	70Hp	80Hp	90Hp	120Hp
—	—	—	—	6 min	5 min	4 min	—	—

3P40

Price	20Hp	30Hp	40Hp	60Hp	70Hp	80Hp	90Hp	120Hp
—	—	—	—	6 min	5 min	4 min	3 min	2 min

WLD007601 Extension Kit

If the tractor you are using with the 1P14 measures less than 20 inches from the PTO lock groove to the center of the lower link arm pin holes, you will require the D007601 Extension Kit

How does it work?

The extension brackets attach to the 1P14’s 3PH mounting bracket. The extension brackets allow you to increase the installed length of the PTO shaft and maximize shaft overlay through the 3PH range of movement.

How to Measure?

Measure dimensions (A) from the PTO lock groove to the center of the lower link arm pin holes. If the dimensions (A) are less than 20 inches, you will require the D007601 extension kit.
