WLD001096
Baumalight 1/2″ Body Female Quick Coupler | 1″ Tip x 1/2″ NPT | 25/1 B Dimension | 12.5 ISO
$80.00
Hydraulic Coupler Size & Pricing
Baumalight offers a range of hydraulic couplers, including ISO 5675, Pioneer, and John Deere compatible couplers. These couplers are available in various sizes to meet the needs of different Skidsteer brands and models.
To measure the size of hydraulic couplers for your baumalight attachments, you only need to measure the dimension as illustrated in the B dimension diagram, know NPT thread size, & body size.
| PART NUMBER | DESCRIPTION | “B” DIMENSION | ISO SIZE | BODY SIZE(in) | WEIGHT(lbs) |
| D001061 | 0.63″ x 1/4″ NPT Male Quick Coupler | 16/0.63 | 6.3 | 1/4 | 1 |
| D002111 | 0.63″ x 1/4″ NPT FM Quick Coupler | 16/0.63 | 6.3 | 1/4 | 1 |
| D001062 | 0.79″ x 1/2″ NPT Male Quick Coupler | 20/0.79 | 10 | 3/8 | 1 |
| D002128 | 0.79″ x 1/2″ NPT FM Quick Coupler | 20/0.79 | 10 | 3/8 | 1 |
| D001063 | 1″ x 1/2″ NPT Male Standard Flow Quick Coupler | 25 / 1.00 | 12.5 | 1/2 | 1 |
| D001096 | 1″ x 1/2″ NPT FM Standard Flow Quick Coupler | 25/1.00 | 12.5 | 1/2 | 1.2 |
| D002109 | 1″ x 3/4″ NPT Male Standard Flow Quick Coupler | 25/1.00 | 12.5 | 1/2 | 1 |
| D002108 | 1″ x 3/4″ NPT FM Standard Flow Quick Coupler | 25 / 1.00 | 12.5 | 1/2 | 1 |
| D001064 | 1.06″ x 3/4″ NPT Male Quick Coupler | 27 /1.06 | 16 | 5/8 | 1 |
| D001097 | 1.06″ x 3/4″ NPT FM Quick Coupler | 27 /1.06 | 16 | 5/8 | 1.2 |
| D001065 | 1.18″ x 3/4″ NPT Male Quick Coupler | 30/ 1.18 | 19 | 3/4 | 1 |
| D001090 | 1.18″ x 3/4″ NPT FM Quick Coupler | 30/1.18 | 19 | 3/4 | 2 |
| D001066 | 1.42″ x 3/4″ NPT Male Quick Coupler | 36/1.42 | 25 | 1 | 1.5 |
| D002110 | 1.42″ x 3/4″ NPT FM Quick Coupler | 36/1.42 | 25 | 1 | 1 |
| D001093 | Pioneer Quick Coupler Male 1/2″ NPT | Â – | – | 1/2 | 1 |
| D001094 | Pioneer Quick Coupler Female 1/2″ NPT | – | – | – | 1 |
