WOSSPF-448

Universal Skid Pallet Fork | Step-Through | Rail Style | Rated 4,000 Lbs. | 1.375″ x 4″ x 48″ Forks

$1,393.00

Weight: 359lbs

Universal Skid Pallet Fork | Step-Through | Rail Style | Rated 4,000 Lbs. | 1.375″ x 4″ x 48″ Forks

For Skid Steer & Tractor Front Loaders with the “Universal” Quick Attach System For Tractor Loaders
Model SSPF-442 SSPF-448 SSPF-5548 SSPF-5560 SSPF-3748 SSPF-3755 SSPF-3760 PF-448
Equipment Used On Skid Steer Loader Skid Steer Loader Skid Steer Loader Skid Steer Loader Skid Steer Loader Skid Steer Loader Skid Steer Loader Tractor Loader
Capacity (lbs/kg) 4,000 / 1,814 4,000 / 1,814 5,500 / 2,495 5,500 / 2,495 4,000 / 1,814 5,500 / 2,495 5,500 / 2,495 4,000 / 1,814
Frame Construction Welded Steel Welded Steel Welded Steel Welded Steel Welded Steel Welded Steel Welded Steel Welded Steel
Backstop Step-through Step-through Step-through Step-through Single Piece Single Piece Single Piece Bolt-on
Mounting “Universal” Skid Steer “Universal” Skid Steer “Universal” Skid Steer “Universal” Skid Steer “Universal” Skid Steer “Universal” Skid Steer “Universal” Skid Steer Mgt. Brt. Available*
Fork Spacing (in/mm) 6 – 40 / 152 – 1016 6 – 40 / 152 – 1016 6 – 40 / 152 – 1016 6 – 40 / 152 – 1016 6 – 40 / 152 – 1016 6 – 40 / 152 – 1016 6 – 40 / 152 – 1016 6 – 40 / 152 – 1016
Fork Carrier Beveled Notched Rail Beveled Notched Rail Beveled Notched Rail Beveled Notched Rail Beveled Notched Rail Beveled Notched Rail Beveled Notched Rail Beveled Notched Rail
Forks 1.375” x 4” w/Latch 1.375” x 4” w/Latch 1.57” x 4” w/Latch 1.57” x 4” w/Latch 1.375” x 4” w/Latch 1.57” x 4” w/Latch 1.57” x 4” w/Latch 1.375” x 4” w/Latch
Fork Length (in/mm) 42 / 1067 48 / 1219 48 / 1219 60 / 1524 48 / 1219 48 / 1219 60 / 1524 48 / 1219
Weight (lbs/kg) 356 /162 370 /168 410 / 186 445 / 202 375 / 170 415 / 188 450 / 204 438 / 199
Product No. 832400 832415 832495 832510 831370 831380 831385 831830

*Optional interfacing quick attach brackets available for most popular loaders.

Note: Rated lift capacity is based on a pair of forks with no more than 1/2 – load per fork and load no more than halfway out on each fork.

⚠ Be sure power unit is properly counterbalanced. Damage to equipment or personal injury could occur.

⚠ Do not handle loads where the weight exceeds the rated lift capacity of the loader.

______________________________________________________________________________________________________________________________________________________________________________________________________

PRICES DO NOT INCLUDE SHIPPING OR SETUP – PRICED F.O.B. ATWOOD

Weight 359 lbs
