HSAR2212
H&S AR2212 12 Wheel Action Rake | 60″ Rake Wheels | 4′-6′ Windrow Width | 20′-24′ Raking Width
$14,282.00
Weight: 1860lbs
H&S 2200 & 3200 Series Action Rakes
- High Clearance Action Rakes Features Immediate Clearance Of Windrows When Raised, As Well As Greater Clearance In The Raking Position & Stability During Transport.
- Raking Width Is Easily Adjusted By A Single Pin & Clip.
- Backbone / Wing Design – When Raised, Allows The Uniform Release Of Crop To Finish The Windrow.
- Easy Rake Wheel Down Pressure Adjustment – The operator can adjust the fine tune nut to allow proper rake wheel down pressure on each arm.
- 60″ Dia Rake Wheels With 7.5mm Teeth
- Dual Hyd Cylinders
- Hydraulic Hoses With Tips
- 205/75D15 Tires
- Adjustable Hitch Allows You To Level The Rake For Efficient Raking
- Jack
- 2200 Series – Linkage System Compression Springs Absorb Rake Wheel Shock For Smooth Travel Over The Ground.
- 3200 Series – Features An Independent Rake Wheel Suspension.
| 2208 | |
|---|---|
| NUMBER OF RAKE WHEELS | 8 |
| WHEEL DIAMETER | 60″ |
| TEETH PER WHEEL | 40 |
| TOOTH DIAMETER | 7.5mm |
| RAKE WHEEL HUBS | Tapered Bearings |
| TRANSPORT WIDTH | 12′ |
| TRANSPORT LENGTH | 19′ 1″ |
| RAKING WIDTH | 16’ 6” – 17’ 8” |
| WINDROW WIDTH ADJUSTMENT | 4’ 5” – 6’ 10” |
| NO. OF RAKING POSITIONS | 6 |
| GROUND PRESSURE RAKE WHEEL ADJUSTMENT | Adjustable Nut on Rod |
| REQUIRED TRACTOR HYDRAULICS | 2 Hose / 1 Remote |
| REQUIRED HYDRAULIC PSI | 1,875# |
| WING CYLINDERS | 2″ |
| JACK | Standard |
| TIRES | ST205/75R15 |
| WEIGHT | 1,437# |
| ONE-SIDED RAKING | Optional |
| TURNBUCKLE ADJUSTMENT KIT | Optional |
| HIGHWAY LIGHTING KIT | Optional |
| SINGLE CENTER KICKER WHEEL | Optional |
| 2210 | |
|---|---|
| NUMBER OF RAKE WHEELS | 10 |
| WHEEL DIAMETER | 60″ |
| TEETH PER WHEEL | 40 |
| TOOTH DIAMETER | 7.5mm |
| RAKE WHEEL HUBS | Tapered Bearings |
| TRANSPORT WIDTH | 12′ |
| TRANSPORT LENGTH | 20′ 5″ |
| RAKING WIDTH | 18’ 5” – 21’ |
| WINDROW WIDTH ADJUSTMENT | 3’ 3” – 7’ 3” |
| NO. OF RAKING POSITIONS | 6 Narrow / 6 Wide |
| GROUND PRESSURE RAKE WHEEL ADJUSTMENT | Adjustable Nut on Rod |
| REQUIRED TRACTOR HYDRAULICS | 2 Hose / 1 Remote |
| REQUIRED TRACTOR HYDRAULICS | 1,875# |
| WING CYLINDERS | 2″ |
| JACK | Standard |
| TIRES | ST205/75R15 |
| WEIGHT | 1,633# |
| ONE-SIDED RAKING | Optional |
| TURNBUCKLE ADJUSTMENT KIT | Optional |
| HIGHWAY LIGHTING KIT | Optional |
| SINGLE CENTER KICKER WHEEL | Optional |
| 2212 | |
|---|---|
| NUMBER OF RAKE WHEELS | 12 |
| WHEEL DIAMETER | 60″ |
| TEETH PER WHEEL | 40 |
| TOOTH DIAMETER | 7.5mm |
| RAKE WHEEL HUBS | Tapered Bearings |
| TRANSPORT WIDTH | 12′ |
| TRANSPORT LENGTH | 21′ 3″ |
| RAKING WIDTH | 21′ – 24′ 4″ |
| WINDROW WIDTH ADJUSTMENT | 2’ 10” – 7’ 3” |
| NO. OF RAKING POSITIONS | 6 Narrow / 6 Wide |
| GROUND PRESSURE RAKE WHEEL ADJUSTMENT | Adjustable Nut on Rod |
| REQUIRED TRACTOR HYDRAULICS | 2 Hose / 1 Remote |
| REQUIRED TRACTOR HYDRAULICS | 1,875# |
| WING CYLINDERS | 2″ |
| JACK | Standard |
| TIRES | ST205/75R15 |
| WEIGHT | 1,794# |
| ONE-SIDED RAKING | Optional |
| TURNBUCKLE ADJUSTMENT KIT | Optional |
| HIGHWAY LIGHTING KIT | Optional |
| SINGLE CENTER KICKER WHEEL | Optional |
| 3210 | |
|---|---|
| NUMBER OF WHEELS | 10 |
| WHEEL DIAMETER | 60″ |
| TEETH PER WHEEL | 40 |
| TOOTH DIAMETER | 7.5mm |
| RAKE WHEEL HUBS | Tapered Bearings |
| TRANSPORT WIDTH | 12′ |
| TRANSPORT LENGTH | 20′ 5″ |
| RAKING WIDTH | 18’ 5” – 21’ |
| WINDROW WIDTH ADJUSTMENT | 3’ 3” – 7’ 3” |
| NO. OF RAKING POSITIONS | 6 Narrow / 6 Wide |
| GROUND PRESSURE RAKE WHEEL ADJUSTMENT | Adjustable Nut on Rod |
| REQUIRED TRACTOR HYDRAULICS | 2 Hose / 1 Remote |
| REQUIRED TRACTOR HYDRAULICS | 1,875# |
| WING CYLINDERS | 2″ |
| JACK | Standard |
| TIRES | ST205/75R15 |
| WEIGHT | 2,000# |
| ONE-SIDED RAKING | Optional |
| TURNBUCKLE ADJUSTMENT KIT | Optional |
| HIGHWAY LIGHTING KIT | Optional |
| CENTER KICKER WHEEL | Optional |
| OSCILLATING TANDEM AXLE ASSEMBLY | Optional |
| 3212 | |
|---|---|
| NUMBER OF WHEELS | 12 |
| WHEEL DIAMETER | 60″ |
| TEETH PER WHEEL | 40 |
| TOOTH DIAMETER | 7.5mm |
| RAKE WHEEL HUBS | Tapered Bearings |
| TRANSPORT WIDTH | 12′ |
| TRANSPORT LENGTH | 21′ 3″ |
| RAKING WIDTH | 21’ – 24’ 4” |
| WINDROW WIDTH ADJUSTMENT | 2’ 10” – 7’ 3” |
| NO. OF RAKING POSITIONS | 6 Narrow / 6 Wide |
| GROUND PRESSURE RAKE WHEEL ADJUSTMENT | Adjustable Nut on Rod |
| REQUIRED TRACTOR HYDRAULICS | 2 Hose / 1 Remote |
| REQUIRED TRACTOR HYDRAULICS | 1,875# |
| WING CYLINDERS | 2″ |
| JACK | Standard |
| TIRES | ST205/75R15 |
| WEIGHT | 2,250# |
| ONE-SIDED RAKING | Optional |
| TURNBUCKLE ADJUSTMENT KIT | Optional |
| HIGHWAY LIGHTING KIT | Optional |
| CENTER KICKER WHEEL | Optional |
| OSCILLATING TANDEM AXLE ASSEMBLY | Optional |
Turnbuckle Adj Kit For Wing Width | For 2200 & 3200 Series (Started Coming Std W/ 3200 In 2024)
$186.00
One Sided Raking Valve Kit | For 2200 & 3200 Series Rakes (Started Coming Std W/ 3200 In 2024)
$233.00
| Weight | 1860 lbs |
|---|
