Worksaver Rail Style Pallet Forks | Bolt-On/Weld-On Quick Attach Bracket Mount | 4,000 lbs Capacity | 1-3/8″ x 4″ x 48″ Forks
Price Does Not Include Setup Or Shipping – F.O.B. Factory
*Loader Brackets Must Be Added To Complete Unit
*Will Not Fit 280 JD Loaders
*Not For Use On Bi-Directional Loaders
Worksaver Quick Attach Bracket Mounted Pallet Forks
- Designed to mount to loaders with center to center between arms no greater than 50”
- Premium forks include spring loaded latches for easy adjustment spacing.
- Optional interfacing quick-attach brackets are available for the model PF-448 for most popular loader models.
- Machined rails allow ease of fork spacing adjustment.
- All models feature solid steel alloy forks for long life, with spring loaded latches for easy adjustment spacing.
|Equipment Used On||Tractor Loader|
|Capacity (lbs/kg)||4,000 / 1,814|
|Frame Construction||Welded Steel|
|Mounting||Mgt. Brt. Available*|
|Fork Spacing (in/mm)||6 – 40 / 152 – 1016|
|Fork Carrier||Beveled Notched Rail|
|Forks||1.375” x 4” w/Latch|
|Fork Length (in/mm)||48 / 1219|
|Weight (lbs/kg)||438 / 199|
Note: Rated lift capacity is based on a pair of forks with no more than 1/2 – load per fork and load no more than halfway out on each fork.
⚠ Be sure power unit is properly counterbalanced. Damage to equipment or personal injury could occur.
⚠ Do not handle loads where the weight exceeds the rated lift capacity of the loader.
