WFS10-9LP
Westfield 10″ x 9′ Low Profile Transfer Auger
$4,064.00
Weight: 555lbs
Shipped Complete With
- Four wheels
- 9ft Tube Section
- Rubber hopper extension
- Safety shields
| Hopper Height – less rubber with wheels | Hopper Height – with rubber with wheels | Hopper Length | Total Length to center of spout | Hopper Width | Spout Height | Tube Length | Tube Dia. | Hyd. Requirements | Elect. HP Requirements | ||
| A | B | C | D | E | F | G | H | ||||
| Std. | S08-6 | 10¾” | 14½” | 48″ | 116″ | 32″ | 26″ | 6ft. | 8″ | 8-10 GPM 1500 PSI | 3-5 HP |
| S08-9 | 10¾” | 14½” | 48″ | 148″ | 32″ | 40½” | 9ft. | 8″ | 8-10 GPM 1500 PSI | 3-5 HP | |
| S10-6 | 12¼” | 16″ | 48″ | 116″ | 32″ | 26½” | 6ft. | 10″ | 10-12 GPM 1500PSI | 5-7.5 HP | |
| S10-9 | 12¼” | 16″ | 48″ | 148″ | 32″ | 41½” | 9ft. | 10″ | 10-12 GPM 1500PSI | 5-7.5 HP | |
| S13-10 | 14¼” | 18¼” | 60″ | 158″ | 40″ | 43″ | 10ft. | 12¾” | N/A | 10-15HP | |
| LP | S10-6 LP | 10½” | 14¼” | 63″ | 18° =146″ 34° =139″ | 40″ | 18° =24″ 34° =43″ | 6ft. | 10″ | 10-12 GPM 1500PSI | 5-7.5 HP |
| S10-9LP | 10½” | 14¼” | 63″ | 18° =180″ 34° =169″ | 40″ | 18° =35″ 34° =63″ | 9ft. | 10″ | 10-12 GPM 1500PSI | 7.5 HP | |
| S13-10LP | 10½” | 14¼” | 63″ | 18° =192″ 34° =180″ | 40″ | 18° =37″ 34° =68 | 10ft. | 12¾” | N/A | 10-15HP | |
| 4″ | 6″ | 7″ | 8″ | 10″ | 13″ | |
| Recommended pulley size for 1750 RPM motors | 1A 2″-2¼ | 2B 3½” – 4″ | 2B 3½” – 4″ | 2B 3¼” – 3½” | 2B 3¼” – 3½” | 3B 3¼” – 3½” |
Hydraulic
Hyd Kit – Less Hose & Hose Connectors
Westfield Hyd Drive Kit | Includes Char-Lynn 2000 Series Hyd Mtr, Mounting Brkt, & Drive Connector
$2,342.00
Electric
Electric Drive Kit (Select)
Westfield Electric Drive Kit | Includes Adjustable Motor Mount, Large Double Pulley, Belts, & Shield
$493.00
| Weight | 555 lbs |
|---|
